The prizes were awarded to the three winners during the Eurammon Symposium.
This year, the Natural Refrigeration Award prize of €5,000 was awarded with support from the Technical University Braunschweig and the Czech trade journal Chlazení.
The prizes were awarded to the three winners on 22 June 2017 during the Eurammon Symposium in Schaffhausen, Switzerland, where they were also able to present and discuss their research relating to the use of natural refrigerants such as ammonia and CO2, with the international expert audience at the symposium.
The first prize was won this year by Peng Gao from Shanghai Jiao Tong University in China. His dissertation related to the development of an innovative solid sorption freezing system for refrigerated trucks. The system uses the exhaust gas generated by combustion of the fuel in the truck engine, at temperatures between 200°C and 500°C, for refrigeration in a two-stage solid sorption freezing cycle operated with the natural refrigerant ammonia. The innovative system is superior to the mechanical vapour compression refrigeration system usually found in refrigerated trucks in terms of both costs and environmental protection; the operating costs and the related CO2 emissions for the refrigeration system are close to zero.
The system is also suitable for refrigerated lorries carrying frozen goods, even in ambient temperatures of up to +30°C. The research results convinced the international jury and triggered great interest among those attending the Eurammon Symposium. Monika Witt, vice-chair of Eurammon stated: 'The dissertation clearly shows the potential of research in the field of natural refrigerants, also indicating the economical and ecological advantages that can be achieved with innovative applications.'
The second prize went to students Dennis Lerch and Stefan Brinkmöller for their project assignment as part of their engineering course at HsKA Karlsruhe University of Applied Sciences in Germany. They developed the BFBGL – the 'Green Line Bavarian Breakfast Preparation Unit'. The mobile high-temperature heat pump has a cold and a hot water basin for cooling 35 bottles of wheat beer from 20°C to 5°C, while at the same time heating 70 Bavarian 'Weisswurst' sausages from 20°C to 80°C. The unit uses the natural refrigerant isobutane (R 600a).
With a view to the high pressure ratio required, a semi-hermetic piston compressor was selected. The beer is cooled by a self-designed tube coil evaporator with medium-high finned tubes, which absorbs the thermal energy effectively through the circulating pump. The condenser was constructed as a plate heat exchanger that transfers the heat to the hot water basin, keeping the refrigerant charge as low as possible. A thermostatic expansion valve was also developed especially for the project. The BFBGL is a prime example of how natural refrigerants can be used practically and efficiently in environmentally friendly refrigeration technology.
The third prize was awarded to the dissertation by Marco Cefarin from the Università degli Studi di Udine in Italy. The aim of the parametric study was to design an NH3-H2O absorption refrigeration system that is also capable of making maximum use of industrial waste heat at low temperatures. A mathematical reference model with a pre-condenser heat exchange dephlegmator reached a COP level of 0.471. While maintaining constant condensating and evaporating temperatures, there was a drop in efficiency at low generator temperatures. The optimum minimum generator temperature was also influenced by different system parameters, such as the size of the heat exchanger and the fluid flow rate. The concentration gradient of ammonia between rich and lean solution was identified as being a central criterion for possibly using a heat recovery concept. The data predicted in the theoretical model were then verified and confirmed in a reference system.
More information about the Natural Refrigeration Award, together with the dissertations and projects of the prizewinners, is available on the Eurammon website at www.eurammon.com.
